TEST ITEM | UNIT | ASTM TEST | TYPICAL VALUES | ||||||||
GAUGE | 10um | 13.5um | 17um | 22um | |||||||
TENSILE | |||||||||||
Tensile Strength (MD) | N/mm² | D882 | 130 | 130 | 130 | 125 | |||||
TensileStrength (TD) | 125 | 125 | 125 | 120 | |||||||
Elongation(MD) | % | 110 | 115 | 120 | 120 | ||||||
Elongation(TD) | 105 | 110 | 110 | 115 | |||||||
TEAR | |||||||||||
MD at 400gm | g | D1922 | 9 | 14.0 | 16.5 | 22.5 | |||||
TD at 400gm | 9.5 | 13.0 | 18.5 | 23.5 | |||||||
SEAL STRENGTH | |||||||||||
MD\HotWire Seal | N/mm | F88 | 0.95 | 1.20 | 1.25 | 1.50 | |||||
TD\HotWire Seal | 1.05 | 1.35 | 1.45 | 1.65 | |||||||
COF(Film To Film) | |||||||||||
Static | D1894 | 0.24 | 0.21 | 0.18 | 0.19 | ||||||
Dynamic | 0.24 | 0.21 | 0.18 | 0.19 | |||||||
OPTICS | |||||||||||
Haze | D1003 | 2.2 | 2.4 | 2.6 | 2.9 | ||||||
Clarity | D1746 | 98.5 | 98.5 | 98.0 | 98.0 | ||||||
Gloss@ 45Deg | D2457 | 89.0 | 88.5 | 88.0 | 86.5 | ||||||
BARRIER | |||||||||||
Oxygen Transmission Rate | cc/㎡/day | D3985 | 12100 | 9700 | 7400 | 6800 | |||||
WaterVapor Transmission Rate | gm/㎡/day | F1249 | 40.5 | 32.5 | 25.5 | 19.5 | |||||
SHRINKAGE PROPERTIES | MD | TD | |||||||||
Free Shrinkage | 100℃ | % | D2732 | 19 | 28 | ||||||
110℃ | 37 | 45 | |||||||||
120℃ | 70 | 72 | |||||||||
130℃ | 81 | 79 | |||||||||
MD | TD | ||||||||||
Shrink Tension | 100℃ | Mpa | D2838 | 2.20 | 2.65 | ||||||
110℃ | 2.65 | 3.80 | |||||||||
120℃ | 2.85 | 4.00 | |||||||||
130℃ | 2.80 | 3.90 |
MD\Machine Direction TD\Transverse Direction
Note: This information represents our better judgment on the work done, but the company assumes no liability whatsoever in connection with the use of information or findings contained herein.
